Double Layer Dryer Fabrics For Paper Machine DRYER Cloth

Name: Double Layer Dryer Fabrics For Paper Machine DRYER Cloth
Brand: ATMC
Price: 1 USD

Place of Origin : China

Brand Name : ATMC

MOQ : 1 pcs

Packaging Details : Standard export ply-wood case

Delivery Time : 30 work days

Payment Terms : L/C，T/T

Price : inquiry

Supply Ability : Purchase supply

Structure : /

Pattern description : /

Mesh × Count (cm) : /

Warp Diameter (mm) : /

Weft Diameter (mm) : /

Warp Material : /

Weft Material : /

Air Permeability : /

Caliper (mm) : /

Elongation (50N/cm) : /

Break Strength : /

Fiber Support Index (FSI) : /

Fiber Support Point (SP) : /

Drainage Index (DI) : /

Paper Side Open Area : /

Void Volume : /

Weight (g/m2 ) : /

Fabric Color : /

Contact Now

DRYER DLR 2404

The DRYER DLR2404 series is a conventional double layer design constructed with round polyester machine direction and cross machine direction yarns, provides good strength and dimensional stability over medium to high air permeability. Fabric construction ensures high dimensional stability and resistance to damage, allows for effective on-the-machine cleaning. Strong non-marking spiral seam ensure easy install and provide good strength, good surface and good resistance.

· Seam Type: Spiral Seam, Pin Seam, Joined Endless

· Width: Up to 10 M

· Applications: Any conventional dryer section for Wrapping and Packaging Papers, Board Grades, Printing & Writing Papers

Features and benefits:

1. Good strength and dimensional stability.

2. High permeability.

3. High abrasion resistance.

4. Monofilament fabric allows effective

on-the-machine cleaning.

5. Large non-marking inline spiral seam ensure

easy install and provide good strength, good

surface and good resistance.

6. Pin seam provide good strength and good

surface for non-woven industries.

Double Layer Dryer Fabrics For Paper Machine DRYER Cloth

Paper Side
